Check Valve Bolted Bonnet

Check Valve Quick Closing Non-return Valve

Check Valves Pressure Seal Bonnet

Forged Steel Check Valves

Check Valves Pressure Seal Cover

Superior Quality High Pressure Check Valves

IPC Valves’ Globe Valves with Pressure Seal Bonnet. Crafted with precision, they excel in high-pressure applications, delivering exceptional performance and reliability. The Pressure Seal Bonnet ensures a secure and leak-free seal, even in extreme conditions, guaranteeing system integrity and safety. Ideal for industries like oil and gas, power generation, and petrochemicals, our Globe Valves with Pressure Seal Bonnet provide precise flow control and durability.

Benefits

Secure and leak-free sealing capability
High-pressure performance and reliability
Enhanced system safety and integrity
Long-lasting durability and reduced maintenance
Versatile application in various industries

Specifications

Pressure rating ASME class 150 through 4500
Sizes - 2" to 24" (dn-50 to dn-600)
MFG standards - BS 1868 / ASME B16.34
Flange details - std as per ASME B16.5
Others as per BS, AWWA, EN, DIN, etc.
End to end dimensions - as per ASME B16.10
Testing standards - API 598 / BS EN 12266-part 1
Butt-weld end details - as per ASME B16.25

Features

- Seat rings in Check Valves are seal welded with the body to eliminate leakage and accidental loosening
- Seating surfaces in high pressure Valves are hard faced with Stellite6 or equivalent
- Flanges: Standard as per B16.5, and others as per BS, AWWA, EN, DIN Et
- Automatically adjusts the slight misalignments caused by pipeline deflections & thermal deformation
- In high pressure Valves, pressure-seal bonnet design with its innovative features enhance the performance & safety
- Stainless Steel Valves are featured with integral seat design
